1-1393302-0
lmages are for reference only.1-1393302-0
RELAY GEN PURPOSE SPDT 40A 12V
Datasheet-
44,410 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1-1393302-0
| Category | Relays - Automotive Relays - |
| Manufacturer | TE Connectivity Potter & Brumfield Relays |
| Series | VF4 |
| Packaging | Bulk |
| RoHS Status | |
| Coil Type | Non Latching |
| Coil Voltage | 12VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 40 A |
| Switching Voltage | 14VDC - Nom |
| Must Operate Voltage | 7.2 VDC |
| Must Release Voltage | 1.2 VDC |
| Operate Time | 7 ms |
| Release Time | 2 ms |
| Features | Resistor |
| Mounting Type | Chassis Mount |
| Termination Style | Plug In, Quick Connect - 0.250" (6.3mm) |
| Operating Temperature | -40°C ~ 125°C |
| Contact Material | Silver Nickel (AgNi) |
| Coil Power | 1.6W |
| Coil Resistance | 90 Ohms |
| Base Product Number | VF4 |
| Coil Current | 133 mA |
| Product Attribute | |
 |
|
|
| Part Number | 1-1393302-0 | 1-1393302-6 | 1-1393302-6 | 1-1393302-9 |
| Manufacturer | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | RELAY GEN PURPOSE SPDT 40A 12V | RELAY AUTOMOTIVE SPST 70A 12V | RELAY AUTOMOTIVE SPST 70A 12V | RELAY MINI PLUG-IN |
| Series | VF4 | VF7 | VF7 | V23134, AXICOM |
| Packaging | Bulk | Tray | Tray | Bulk |
Recommended Products
