Part Number
1-1415021-1
Manufacturer
TE Connectivity Potter & Brumfield RelaysDescription
PT570L48
Datasheet
DatasheetPackage
-
In Stock
82,061 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation

1-1415021-1
lmages are for reference only.1-1415021-1
PT570L48
Datasheet-
82,061 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods

Delivery Services

General Purpose Relay 4PDT (4 Form C) 48VDC Coil Socketable
1-1415021-1

| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | TE Connectivity Potter & Brumfield Relays |
| Series | PT, SCHRACK |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Socketable |
| Coil Voltage | 48VDC |
| Contact Form | 4PDT (4 Form C) |
| Contact Rating (Current) | 6 A |
| Switching Voltage | 240VAC - Max |
| Load - Max Switching | 1440VA |
| Coil Current | 15.6 mA |
| Coil Type | Non Latching |
| Features | Diode, Lighted Indicator, Test Button |
| Termination Style | Plug In, Quick Connect - 0.110" (2.8mm) |
| Seal Rating | - |
| Coil Insulation | Class F |
| Must Operate Voltage | 36 VDC |
| Must Release Voltage | 4.8 VDC |
| Operate Time | 15 ms |
| Release Time | 10 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Nickel (AgNi) |
| Approval Agency | cURus, VDE |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 3.072 kOhms |
| Base Product Number | PT570 |

| Product Attribute | ![]() |
![]() |
![]() |
![]() |
| Part Number | 1-1415020-1 | 1-1415026-1 | 1-1414147-0 | 1-1414286-0 |
| Manufacturer | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant | RoHS Compliant |
| Description | RELAY GEN PURPOSE DPDT 6V | RELAY GEN PURPOSE DPDT 12A 230V | RELAY GEN PURPOSE SPST 70A 12V | RELAY GEN PURPOSE SPST 70A 12V |
| Series | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Packaging | Tube | Box | Bulk | Bulk |
