110IMY35D05D05-8
lmages are for reference only.110IMY35D05D05-8
DC DC CONVERTER 5V 5V 5V
Datasheet19-DIP Module, 17 Leads
82,300 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Isolated Module DC DC Converter 4 Output 5V 5V 5V 1.4A, 1.4A, 1.4A 60V - 150V Input
110IMY35D05D05-8
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Bel Power Solutions |
| Series | Melcher IMY35 (35W) |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module |
| Number of Outputs | 4 |
| Voltage - Input (Min) | 60V |
| Voltage - Input (Max) | 150V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | 5V |
| Voltage - Output 3 | 5V |
| Voltage - Output 4 | - |
| Current - Output (Max) | 1.4A, 1.4A, 1.4A |
| Power (Watts) | - |
| Applications | ITE (Commercial) |
| Features | Remote On/Off, OCP, OTP, OVP, SCP, UVLO |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 87% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 19-DIP Module, 17 Leads |
| Size / Dimension | 3.00" L x 2.50" W x 0.41" H (76.2mm x 63.5mm x 10.5mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | 110IMY35 |
| Voltage - Isolation | 2.5 kV |
| Product Attribute |  |
|
 |
|
| Part Number | 110IMY15-03-8RG-G | 110IMY15-05-05-8 | 110IMY15-05-05-8G | 110IMY15-05-8R |
| Manufacturer | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER 3.3V 15W | DC DC CONVERTER 5V 5V 15W | DC DC CONVERTER 5V 5V 15W | DC DC CONVERTER 5.1V 15W |
| Series | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions |
| Packaging | Bulk | Bulk | Bulk | Bulk |
