1120-391K
lmages are for reference only.1120-391K
FIXED IND 390UH 1.6A 320 MOHM TH
DatasheetRadial, Vertical Cylinder
48,581 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
390 µH Unshielded Drum Core, Wirewound Inductor 1.6 A 320mOhm Max Radial, Vertical Cylinder
1120-391K
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Bourns Inc. |
| Series | 1120 |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 390 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 1.6 A |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 320mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -55°C ~ 105°C |
| Inductance Frequency - Test | 1 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder |
| Supplier Device Package | - |
| Size / Dimension | 0.810" Dia (20.57mm) |
| Height - Seated (Max) | 0.840" (21.34mm) |
| Base Product Number | 1120 |
| Product Attribute |  |
|
|
|
| Part Number | 1120-391K-RC | 1120-391K-RC | 1120-330K | 1120-330K-RC |
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | IND0.62X.81X.84IN,390UH10%1.6A,N | IND0.62X.81X.84IN,390UH10%1.6A,N | FIXED IND 33UH 5.5A 29 MOHM TH | FIXED IND 33UH 5.5A 29 MOHM TH |
| Series | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Packaging | Bulk | Bulk | Bulk | Bulk |
