1618239-1
lmages are for reference only.1618239-1
K40P-01=RELAY, VAC SPST LATCHING
Datasheet-
94,992 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay SPST-NO (1 Form A) Coil Panel Mount
1618239-1
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | K40, KILOVAC |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Mounting Type | Panel Mount |
| Coil Voltage | - |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 35 A |
| Switching Voltage | 5000VDC - Nom |
| Load - Max Switching | - |
| Coil Current | - |
| Coil Type | Latching, Dual Coil |
| Features | - |
| Termination Style | Wire Leads |
| Seal Rating | - |
| Coil Insulation | - |
| Must Operate Voltage | 16 VDC |
| Must Release Voltage | - |
| Operate Time | 1 ms |
| Release Time | - |
| Operating Temperature | -55°C ~ 125°C |
| Contact Material | - |
| Approval Agency | - |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 80 Ohms |
| Base Product Number | 1618239 |
| Product Attribute |  |
|
 |
|
| Part Number | 1618239-2 | 1618239-3 | 1618239-4 | 1611748-9 |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | |
| Description | RELAY | K40P-03=RELAY, VACUUM, SPST, L | RELAY K40P SERIES HIGH VOLTAGE | Electromechanical, Relays |
| Series | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity |
| Packaging | Bulk | Bulk | Bulk | Bulk |
