Product Catalog

1825290-6

1825290-6

1825290-6

lmages are for reference only.

Request for Quotation

  • Payment Methods

  • Delivery Services

Slide Switch DP3T Through Hole, Right Angle

Quick Inquiry

1825290-6

Get the Price Now!

Specifications

Category Switches - Slide Switches -
Manufacturer TE Connectivity ALCOSWITCH Switches
Series MHS
Packaging Bulk
RoHS Status ROHS3 Compliant
Circuit DP3T
Contact Timing Shorting (MBB)
Switch Function On-On-On
Current Rating (Amps) 0.4VA (AC/DC)
Voltage Rating - AC 20 V
Voltage Rating - DC 20 V
Actuator Type Standard
Actuator Length 4.50mm
Contact Material Copper Alloy
Contact Finish Gold
Mounting Type Through Hole, Right Angle
Termination Style PC Pin
Features Epoxy Sealed Terminals
Operating Temperature -20°C ~ 85°C
Actuator Material Polyoxymethylene (Acetal) (POM)
Switch Travel 2.00mm
Mechanical Life 15,000 Cycles
Electrical Life 15,000 Cycles
Operating Force 600gf
Base Product Number 1825290

Parts with Similar Specifications

Product Attribute 1825290-5 1825198-2 1825159-4 1825031-3
Part Number 1825290-5 1825198-2 1825159-4 1825031-3
Manufacturer TE Connectivity ALCOSWITCH Switches TE Connectivity ALCOSWITCH Switches TE Connectivity ALCOSWITCH Switches TE Connectivity ALCOSWITCH Switches
RoHS Status Not applicable ROHS3 Compliant Not applicable ROHS3 Compliant
Description SWITCH SLIDE DPDT 0.4VA 20V SWITCH SLIDE DP3T 0.4VA 20V SWITCH SLIDE SP5T 300MA 125V SWITCH SLIDE DPDT 0.4VA 20V
Series MHS MSSA STS SE
Packaging Bulk Tray Bulk Bulk
