18R254C
lmages are for reference only.18R254C
FIXED IND 250UH 800MA 255MOHM TH
DatasheetRadial, Vertical Cylinder
93,830 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
250 µH Unshielded Wirewound Inductor 800 mA 255mOhm Max Radial, Vertical Cylinder
18R254C
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Murata Power Solutions Inc. |
| Series | 1800R |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 250 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 800 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 255mOhm Max |
| Q @ Freq | 40 @ 100kHz |
| Frequency - Self Resonant | 3.85MHz |
| Ratings | - |
| Operating Temperature | 0°C ~ 70°C |
| Inductance Frequency - Test | 1 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder |
| Supplier Device Package | Radial Lead |
| Size / Dimension | 0.539" Dia (13.70mm) |
| Height - Seated (Max) | 0.626" (15.90mm) |
| Base Product Number | 18R |
| Product Attribute |  |
|
 |
|
| Part Number | 18R223C | 18R223C | 18R224C | 18R225C |
| Manufacturer | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 22UH 2.42A 25 MOHM TH | FIXED IND 22UH 2.42A 25 MOHM TH | FIXED IND 220UH 900MA 230MOHM TH | FIXED IND 2.2MH 300MA 2.2 OHM TH |
| Series | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. |
| Packaging | Bulk | Bulk | Bulk | Bulk |
