High-Side or Low-Side Gate Driver IC Module
1SP0335V2M1C-MBN1200H45E2-H
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Power Integrations |
| Series | SCALE™-2 |
| Packaging | Tray |
| RoHS Status | |
| Driven Configuration | High-Side or Low-Side |
| Channel Type | Single |
| Number of Drivers | 1 |
| Gate Type | IGBT |
| Voltage - Supply | 23.5V ~ 26.5V |
| Logic Voltage - VIL, VIH | - |
| Current - Peak Output (Source, Sink) | 35A, 35A |
| Input Type | - |
| High Side Voltage - Max (Bootstrap) | 4500 V |
| Rise / Fall Time (Typ) | 9ns, 30ns |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | Module |
| Base Product Number | 1SP0335 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | 1SP0335V2M1C-5SNA0400J650100 | 1SP0335V2M1C-5SNA0600G650100 | 1SP0335V2M1C-5SNA0750G650300 | 1SP0335V2M1C-5SNA1200G450300 |
| Manufacturer | Power Integrations | Power Integrations | Power Integrations | Power Integrations |
| RoHS Status | ||||
| Description | IC GATE DRVR HI/LOW SIDE MODULE | IC GATE DRVR HI/LOW SIDE MODULE | IC GATE DRVR HI/LOW SIDE MODULE | IC GATE DRVR HI/LOW SIDE MODULE |
| Series | SCALE™-2 | SCALE™-2 | SCALE™-2 | SCALE™-2 |
| Packaging | Tray | Tray | Tray | Tray |
