2102870-1
lmages are for reference only.2102870-1
CONN PLUG VITA46 112POS EDGE MNT
Datasheet-
88,598 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
112 Connector Plug, Male Blades Board Edge, Through Hole, Right Angle Black VITA 46, Right End
2102870-1
| Category | Connectors, Interconnects - Backplane Connectors - Specialized |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | MULTIGIG RT2-R |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Connector Usage | Daughtercard |
| Connector Type | Plug, Male Blades |
| Connector Style | VITA 46, Right End |
| Number of Positions | 112 |
| Number of Positions Loaded | All |
| Pitch | 0.071" (1.80mm) |
| Number of Rows | 7 |
| Number of Columns | 16 |
| Mounting Type | Board Edge, Through Hole, Right Angle |
| Termination | Press-Fit |
| Contact Layout, Typical | - |
| Features | Board Guide |
| Contact Finish | Gold |
| Contact Finish Thickness | 50.0µin (1.27µm) |
| Color | Black |
| Current Rating (Amps) | - |
| Material Flammability Rating | UL94 V-0 |
| Operating Temperature | -55°C ~ 105°C |
| Voltage Rating | 50V |
| Base Product Number | 2102870 |
| Product Attribute |  |
 |
|
|
| Part Number | 2101510-2 | 2101536-2 | 2101536-3 | 2101536-5 |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| RoHS Status | ROHS3 Compliant | Not applicable | Not applicable | Not applicable |
| Description | 4 POS RF MODULE, BACKPLANE, OSMM | GPRB1 RECPT ASSY, 3P3 W/SOCKET C | GPRB1 RECPT ASSY, 3P3 W/SOCKET C | GPRB1 RECPT ASSY, 3P3 W/SOCKET C |
| Series | SMPM | * | * | * |
| Packaging | Bulk | Bulk | Bulk | Bulk |
