2200HT-4R7-H-RC
lmages are for reference only.2200HT-4R7-H-RC
FIXED IND 4.7UH 16.9A 6 MOHM TH
DatasheetRadial, Horizontal (Open)
69,639 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
4.7 µH Shielded Toroidal Inductor 16.9 A 6mOhm Max Radial, Horizontal (Open)
2200HT-4R7-H-RC
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Bourns Inc. |
| Series | 2200HT |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Type | Toroidal |
| Material - Core | Iron Powder |
| Inductance | 4.7 µH |
| Tolerance | ±15% |
| Current Rating (Amps) | 16.9 A |
| Current - Saturation (Isat) | - |
| Shielding | Shielded |
| DC Resistance (DCR) | 6mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -55°C ~ 200°C |
| Inductance Frequency - Test | 1 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Horizontal (Open) |
| Supplier Device Package | - |
| Size / Dimension | 0.950" Dia (24.13mm) |
| Height - Seated (Max) | 0.550" (13.97mm) |
| Base Product Number | 2200HT |
| Product Attribute |  |
 |
|
|
| Part Number | 2200HT-4R7-V-RC | 2200HT-100-H-RC | 2200HT-100-H-RC | 2200HT-101-H |
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | FIXED IND 4.7UH 16.9A 6 MOHM TH | FIXED IND 10UH 11.2A 14 MOHM TH | FIXED IND 10UH 11.2A 14 MOHM TH | FIXED IND 100UH 5.3A 61 MOHM TH |
| Series | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Packaging | Bulk | Tray | Tray | Bulk |
