Product CatalogPart Number
2SA1746
Manufacturer
Sanken Electric USA Inc.Description
TRANS PNP 50V 12A TO-3PF
Datasheet
DatasheetPackage
TO-3P-3 Full Pack
In Stock
93,622 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
2SA1746
2SA1746
lmages are for reference only.Payment Methods
Delivery Services
Bipolar (BJT) Transistor PNP 50 V 12 A 25MHz 60 W Through Hole TO-3PF
Quick Inquiry
2SA1746
Specifications
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Sanken Electric USA Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Transistor Type | PNP |
| Current - Collector (Ic) (Max) | 12 A |
| Voltage - Collector Emitter Breakdown (Max) | 50 V |
| Vce Saturation (Max) @ Ib, Ic | 500mV @ 80mA, 5A |
| Current - Collector Cutoff (Max) | 10µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 50 @ 5A, 1V |
| Power - Max | 60 W |
| Frequency - Transition | 25MHz |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-3P-3 Full Pack |
| Supplier Device Package | TO-3PF |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
