2SD1785
lmages are for reference only.2SD1785
TRANS NPN DARL 120V 6A TO-220F
DatasheetTO-220-3 Full Pack
80,039 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar (BJT) Transistor NPN - Darlington 120 V 6 A 100MHz 30 W Through Hole TO-220F
2SD1785
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Sanken Electric USA Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Transistor Type | NPN - Darlington |
| Current - Collector (Ic) (Max) | 6 A |
| Voltage - Collector Emitter Breakdown (Max) | 120 V |
| Vce Saturation (Max) @ Ib, Ic | 1.5V @ 3mA, 2A |
| Current - Collector Cutoff (Max) | 10µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 2000 @ 3A, 2V |
| Power - Max | 30 W |
| Frequency - Transition | 100MHz |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 Full Pack |
| Supplier Device Package | TO-220F |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | 2SD1781A_R1_00001 | 2SD1781KFRAT146R | 2SD1781KT146Q | 2SD1781KT146R |
| Manufacturer | Panjit International Inc. | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TRANS NPN 50V 3A SOT-23 | TRANS NPN 32V 0.8A SMT3 | TRANS NPN 32V 0.8A SMT3 | TRANS NPN 32V 0.8A SMT3 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
