2SK3058-Z-E1-AZ
lmages are for reference only.2SK3058-Z-E1-AZ
N-CHANNEL POWER MOSFET
DatasheetTO-263-3, D2PAK (2 Leads + Tab), TO-263AB
56,019 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 60 V 55A 1.5W Surface Mount TO-263, TO-220SMD
2SK3058-Z-E1-AZ
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | NEC Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | Not applicable |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 55A |
| Drive Voltage (Max Rds On, Min Rds On) | 4V, 10V |
| Rds On (Max) @ Id, Vgs | 17mOhm @ 28A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 1mA |
| Vgs (Max) | 20V |
| Input Capacitance (Ciss) (Max) @ Vds | 2100 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 1.5W |
| Operating Temperature | -55°C ~ 150°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | TO-263, TO-220SMD |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 45 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 2SK3003 | 2SK3004 | 2SK3018-TP | 2SK3018T106 |
| Manufacturer | Sanken Electric USA Inc. | Sanken Electric USA Inc. | Micro Commercial Co | Rohm Semiconductor |
| RoHS Status | RoHS Compliant | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 200V 18A TO220F | MOSFET N-CH 250V 18A TO220F | MOSFET N-CH 30V 100MA SOT323 | MOSFET N-CH 30V 100MA UMT3 |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
