4100-063
lmages are for reference only.4100-063
FILTER LC(PI) 1500PF TH
DatasheetRadial, Eyelet - PC Pin
32,524 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LC (Pi) EMI Filter 3rd Order Low Pass 1 Channel C = 1500pF 10 A Radial, Eyelet - PC Pin
4100-063
| Category | Filters - EMI-RFI Filters LC-RC Networks - |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components |
| Series | 4100 |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Type | Low Pass |
| Filter Order | 3rd |
| Technology | LC (Pi) |
| Center / Cutoff Frequency | - |
| Attenuation Value | 35dB @ 100MHz |
| Resistance - Channel (Ohms) | - |
| Current | 10 A |
| Values | C = 1500pF |
| ESD Protection | No |
| Operating Temperature | -55°C ~ 125°C |
| Applications | Data Lines for Mobile Devices |
| Voltage - Rated | 380V |
| Mounting Type | Through Hole |
| Package / Case | Radial, Eyelet - PC Pin |
| Size / Dimension | 0.130" Dia x 0.600" L (3.30mm x 15.24mm) |
| Height | - |
| Number of Channels | 1 |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
 |
| Part Number | 4100-063 | 4100-063LF | 4100-063LF | 4100-000LF |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant |
| Description | FILTER LC(PI) 1500PF TH | FILTER LC(PI) 4500PF TH | FILTER LC(PI) 4500PF TH | FILTER LC(PI) 1500PF CUSTOM |
| Series | 4100 | 4100 | 4100 | 4100 |
| Packaging | Bulk | Bulk | Bulk | Bulk |
