FILTER LC(PI) SMD
DatasheetPill, Square
62,003 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LC (Pi) EMI Filter 3rd Order Low Pass 1 Channel L = 0.1µH, C = 1000pF, 1500pF 10 A Pill, Square
4700-011M
| Category | Filters - EMI-RFI Filters LC-RC Networks - |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components |
| Series | 4700 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| Type | Low Pass |
| Filter Order | 3rd |
| Technology | LC (Pi) |
| Center / Cutoff Frequency | - |
| Attenuation Value | 24dB @ 100MHz |
| Resistance - Channel (Ohms) | - |
| Current | 10 A |
| Values | L = 0.1µH, C = 1000pF, 1500pF |
| ESD Protection | No |
| Operating Temperature | -55°C ~ 125°C |
| Applications | Data Lines for Mobile Devices |
| Voltage - Rated | 100V |
| Mounting Type | Surface Mount |
| Package / Case | Pill, Square |
| Size / Dimension | 0.315" L x 0.090" W (8.00mm x 2.29mm) |
| Height | 0.095" (2.41mm) |
| Number of Channels | 1 |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
 |
| Part Number | 4700-011M | 4700-011MLF | 4700-011MLF | 4700-003M |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | FILTER LC(PI) SMD | FILTER LC(PI) SMD | FILTER LC(PI) SMD | FILTER LC(PI) 0.1UH/2000PF SMD |
| Series | 4700 | 4700 | 4700 | 4700 |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
