4N49U
lmages are for reference only.4N49U
OPTOISO 1KV TRANS W/BASE 6LCC
Datasheet6-SMD, No Lead
53,865 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Transistor with Base Output 1000Vrms 1 Channel 6-LCC (6.22x4.32)
4N49U
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | TT Electronics/Optek Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 1 |
| Voltage - Isolation | 1000Vrms |
| Current Transfer Ratio (Min) | 200% @ 2mA |
| Current Transfer Ratio (Max) | - |
| Turn On / Turn Off Time (Typ) | - |
| Rise / Fall Time (Typ) | 20µs, 20µs |
| Input Type | DC |
| Output Type | Transistor with Base |
| Voltage - Output (Max) | 35V |
| Current - Output / Channel | 50mA |
| Voltage - Forward (Vf) (Typ) | 1.5V |
| Current - DC Forward (If) (Max) | 40 mA |
| Vce Saturation (Max) | 300mV |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, No Lead |
| Supplier Device Package | 6-LCC (6.22x4.32) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 4N49 | 4N49A | 4N49TX | 4N49TXV |
| Manufacturer | TT Electronics/Optek Technology | TT Electronics/Optek Technology | TT Electronics/Optek Technology | TT Electronics/Optek Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant |
| Description | OPTOISO 1KV TRANS W/BASE TO78-6 | OPTOISO 1KV TRANS W/BASE TO78-6 | OPTOISO 1KV TRANS W/BASE TO78-6 | OPTOISO 1KV TRANS W/BASE TO78-6 |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
