NOR Gate IC 4 Channel 14-DHXQFN (2x2)
74HCT02BZZ
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | Nexperia USA Inc. |
| Series | 74HCT |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | - |
| Logic Type | NOR Gate |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Max) | 2 μA |
| Current - Output High, Low | 4mA, 5.2mA |
| Input Logic Level - Low | 0.8V |
| Input Logic Level - High | 1.6V |
| Max Propagation Delay @ V, Max CL | 19ns @ 4.5V, 50pF |
| Operating Temperature | -40＜C ~ 125＜C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-DHXQFN (2x2) |
| Package / Case | 14-XFQFN Exposed Pad |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 74HCT02BQ,115 | 74HCT02BQ-Q100,115 | 74HCT02D | 74HCT02D,652 |
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. | Toshiba Semiconductor and Storage | Nexperia USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant | ROHS3 Compliant |
| Description | IC GATE NOR 4CH 2-INP 14DHVQFN | IC GATE NOR 4CH 2-INP 14DHVQFN | IC GATE NOR 4CH 2-INP 14SOIC | IC GATE NOR 4CH 2-INP 14SO |
| Series | 74HCT | 74HCT | 74HCT | 74HCT |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tube |
