74LVC109DB,112
lmages are for reference only.74LVC109DB,112
IC FF JK TYPE DUAL 1BIT 16SSOP
Datasheet16-SSOP (0.209", 5.30mm Width)
77,622 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Flip Flop 2 Element JK Type 1 Bit Positive Edge 16-SSOP (0.209", 5.30mm Width)
74LVC109DB,112
| Category | Integrated Circuits (ICs) - Logic - Flip Flops |
| Manufacturer | NXP USA Inc. |
| Series | 74LVC |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Function | Set(Preset) and Reset |
| Type | JK Type |
| Output Type | Complementary |
| Number of Elements | 2 |
| Number of Bits per Element | 1 |
| Clock Frequency | 330 MHz |
| Max Propagation Delay @ V, Max CL | 6.8ns @ 3.3V, 50pF |
| Trigger Type | Positive Edge |
| Current - Output High, Low | 24mA, 24mA |
| Voltage - Supply | 1.65V ~ 3.6V |
| Current - Quiescent (Iq) | 10 µA |
| Input Capacitance | 5 pF |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 16-SSOP |
| Package / Case | 16-SSOP (0.209", 5.30mm Width) |
| Base Product Number | 74LVC109 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 74LVC109DB,118 | 74LVC109AXTDC | 74LVC109AXTPY | 74LVC109D,112 |
| Manufacturer | NXP USA Inc. | IDT, Integrated Device Technology Inc | IDT, Integrated Device Technology Inc | NXP USA Inc. |
| RoHS Status | ROHS3 Compliant | Not applicable | Not applicable | ROHS3 Compliant |
| Description | IC FF JK TYPE DUAL 1BIT 16SSOP | IC FF JK TYPE DUAL 1BIT 16CDIP | IC FF JK TYPE DUAL 1BIT 16SSOP | IC FF JK TYPE DUAL 1BIT 16SO |
| Series | 74LVC | 74LVC | 74LVC | 74LVC |
| Packaging | Tape & Reel (TR) | Bulk | Bulk | Tube |
