Product Catalog

7687480472

7687480472

7687480472

lmages are for reference only.
  • Part Number

    7687480472

  • Manufacturer

    Würth Elektronik
  • Description

    WE-TI HV RADIAL LEADED WIRE WOUN

  • Datasheet

    DatasheetDatasheet
  • Package

    Radial, Vertical Cylinder

  • In Stock

    92,651 piece(s)

  • Unit Price

    Please Contact Us

  • Lead Time

    Can Ship Immediately

Request for Quotation

  • Payment Methods

  • Delivery Services

4.7 mH Unshielded Wirewound Inductor 300 mA 5.8Ohm Max Radial, Vertical Cylinder

Quick Inquiry

7687480472

Get the Price Now!

Specifications

Category Inductors, Coils, Chokes - Fixed Inductors -
Manufacturer Würth Elektronik
Series WE-TI HV
Packaging Tray
RoHS Status ROHS3 Compliant
Type Wirewound
Material - Core -
Inductance 4.7 mH
Tolerance ±5%
Current Rating (Amps) 300 mA
Current - Saturation (Isat) 420mA
Shielding Unshielded
DC Resistance (DCR) 5.8Ohm Max
Q @ Freq -
Frequency - Self Resonant 630kHz
Ratings -
Operating Temperature -40°C ~ 125°C
Inductance Frequency - Test 10 kHz
Features -
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Supplier Device Package Radial, Vertical Cylinder
Size / Dimension 0.413" Dia (10.50mm)
Height - Seated (Max) 0.571" (14.50mm)
Base Product Number -

Parts with Similar Specifications

Product Attribute 7687480471 7687480102 7687480122 7687480152
Part Number 7687480471 7687480102 7687480122 7687480152
Manufacturer Würth Elektronik Würth Elektronik Würth Elektronik Würth Elektronik
RoHS Status ROHS3 Compliant ROHS3 Compliant ROHS3 Compliant ROHS3 Compliant
Description WE-TI HV RADIAL LEADED WIRE WOUN WE-TI HV RADIAL LEADED WIRE WOUN WE-TI HV RADIAL LEADED WIRE WOUN WE-TI HV RADIAL LEADED WIRE WOUN
Series Würth Elektronik Würth Elektronik Würth Elektronik Würth Elektronik
Packaging Tray Tray Tray Tray
