Product CatalogPart Number
770-814
Manufacturer
WAGO CorporationDescription
PLUG FOR PCBS STRAIGHT 4-POLE, B
Datasheet
DatasheetPackage
-
In Stock
63,982 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
770-814
770-814
lmages are for reference only.Payment Methods
Delivery Services
4 Position Terminal Block Plug, Male Pins 0.394" (10.00mm) 90° Panel Mount
Quick Inquiry
770-814
Specifications
| Category | Connectors, Interconnects - Terminal Blocks - Headers-Plugs and Sockets |
| Manufacturer | WAGO Corporation |
| Series | WINSTA® MIDI |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | - |
| Type | Plug, Male Pins |
| Number of Positions | 4 |
| Positions Per Level | 4 |
| Number of Levels | 1 |
| Pitch | 0.394" (10.00mm) |
| Header Orientation | - |
| Plug Wire Entry | 90° |
| Termination Style | Solder |
| Mounting Type | Panel Mount |
| Current - IEC | 25A |
| Voltage - IEC | 400 V |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Color | Black |
| Operating Temperature | -35°C ~ 85°C |
| Contact Mating Finish | - |
| Features | Locking Feature |
| Material Flammability Rating | UL94 V-0 |
| Ingress Protection | - |
| Screw Size | - |
| Torque - Screw | - |
| Wire Strip Length | - |
| Contact Material | - |
| Housing Material | Polyamide (PA66), Nylon 6/6 |
| Contact Tail Length | 0.138" (3.50mm) |
| Insulation Height | 1.024" (26.01mm) |
| Current - UL | 23 A |
| Voltage - UL | 600 V |
