Product CatalogPart Number
87401-125
Manufacturer
Amphenol ICC (FCI)Description
CONN HEADER SMD 50POS 1.27MM
Datasheet
DatasheetPackage
-
In Stock
53,027 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
87401-125
87401-125
lmages are for reference only.Payment Methods
Delivery Services
Connector Header Surface Mount 50 position 0.050" (1.27mm)
Quick Inquiry
87401-125
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Male Pins |
| Manufacturer | Amphenol ICC (FCI) |
| Series | Rib-Cage™ III |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Connector Type | Header |
| Contact Type | Male Pin |
| Pitch - Mating | 0.050" (1.27mm) |
| Number of Positions | 50 |
| Number of Rows | 2 |
| Row Spacing - Mating | 0.050" (1.27mm) |
| Number of Positions Loaded | All |
| Style | Board to Board |
| Shrouding | Shrouded - 4 Wall |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Fastening Type | Push-Pull |
| Contact Length - Mating | 0.130" (3.30mm) |
| Contact Length - Post | - |
| Overall Contact Length | - |
| Insulation Height | 0.226" (5.74mm) |
| Contact Shape | Square |
| Contact Finish - Mating | Gold or Gold, GXT™ |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | Tin-Lead |
| Contact Material | - |
| Insulation Material | Thermoplastic, Glass Filled |
| Features | Board Guide |
| Operating Temperature | -55°C ~ 130°C |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Insulation Color | Natural |
| Current Rating (Amps) | - |
| Voltage Rating | - |
| Mated Stacking Heights | 6.42mm |
| Contact Finish Thickness - Post | 100.0µin (2.54µm) |
| Applications | - |
| Base Product Number | 87401 |
Parts with Similar Specifications
| Product Attribute |  |
|
|
 |
| Part Number | 87401-125CTLF | 87401-125LF | 87401-110 | 87401-110LF |
| Manufacturer | Amphenol ICC (FCI) | Amphenol ICC (FCI) | Amphenol ICC (FCI) | Amphenol ICC (FCI) |
| RoHS Status | RoHS Compliant | RoHS non-compliant | RoHS Compliant | |
| Description | CONN HEADER SMD 50POS 1.27MM | CONN HEADER SMD 50POS 1.27MM | CONN HEADER SMD 20POS 1.27MM | CONN HEADER SMD 20POS 1.27MM |
| Series | Rib-Cage™ III | Rib-Cage™ III | Rib-Cage™ III | Rib-Cage™ III |
| Packaging | Tube | Tube | Tube | Tube |
