931-HSL/03-HT
lmages are for reference only.931-HSL/03-HT
HEADER FOR 931-HFL SERIES, 3.5 M
Datasheet-
79,749 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
3 Position Terminal Block Header, Male Pins, Partial Shroud 0.138" (3.50mm) Vertical Through Hole
931-HSL/03-HT
| Category | Connectors, Interconnects - Terminal Blocks - Headers-Plugs and Sockets |
| Manufacturer | WECO Electrical Connectors Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | - |
| Type | Header, Male Pins, Partial Shroud |
| Number of Positions | 3 |
| Positions Per Level | 3 |
| Number of Levels | 1 |
| Pitch | 0.138" (3.50mm) |
| Header Orientation | Vertical |
| Plug Wire Entry | - |
| Termination Style | Solder |
| Mounting Type | Through Hole |
| Current - IEC | - |
| Voltage - IEC | - |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Color | Black |
| Operating Temperature | -40°C ~ 120°C |
| Contact Mating Finish | Tin |
| Features | - |
| Material Flammability Rating | UL94 V-0 |
| Ingress Protection | - |
| Screw Size | - |
| Torque - Screw | - |
| Wire Strip Length | - |
| Contact Material | Brass |
| Housing Material | Polyamide (PA), Nylon |
| Contact Tail Length | 0.157" (4.00mm) |
| Insulation Height | 0.429" (10.90mm) |
| Current - UL | 6 A |
| Voltage - UL | 300 V |
| Product Attribute |  |
|
 |
|
| Part Number | 931-FST/02 | 931-FST/03 | 931-SLS/03 | 931-SLS/06 |
| Manufacturer | WECO Electrical Connectors Inc. | WECO Electrical Connectors Inc. | WECO Electrical Connectors Inc. | WECO Electrical Connectors Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | PCB SCREW CONN;2P; 3.5 MM | PCB SCREW CONN;3P; 3.5 MM | PINSTRIP; 3; 0.138 IN., 3.5 MM P | PCB SCREW CONN;6P; 3.5 MM |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
