A3949SLPTR
lmages are for reference only.A3949SLPTR
IC MOTOR DRIVER 8V-36V 16TSSOP
Datasheet16-TSSOP (0.173", 4.40mm Width) Exposed Pad
67,900 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Motor Driver DMOS Parallel 16-eTSSOP-EP
A3949SLPTR
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | Allegro MicroSystems |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushed DC |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (2) |
| Interface | Parallel |
| Technology | DMOS |
| Step Resolution | - |
| Applications | General Purpose |
| Current - Output | 2.8A |
| Voltage - Supply | 8V ~ 36V |
| Voltage - Load | 8V ~ 36V |
| Operating Temperature | -20°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 16-eTSSOP-EP |
| Base Product Number | A3949 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | A3949SLPTR | A3949SLPTR-T | A3949SLPTR-T | A3949SLB |
| Manufacturer | Allegro MicroSystems | Allegro MicroSystems | Allegro MicroSystems | Allegro MicroSystems |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | IC MOTOR DRIVER 8V-36V 16TSSOP | IC MOTOR DRIVER 8V-36V 16TSSOP | IC MOTOR DRIVER 8V-36V 16TSSOP | IC MOTOR DRIVER 8V-36V 16SOIC |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
