Product CatalogPart Number
ACMS-Q3225E-101-T
Manufacturer
Abracon LLCDescription
CMC 150MA 2LN SMD AEC-Q200
Datasheet
DatasheetPackage
Horizontal, 4 PC Pad
In Stock
13,680 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
ACMS-Q3225E-101-T
ACMS-Q3225E-101-T
lmages are for reference only.Payment Methods
Delivery Services
2 Line Common Mode Choke Surface Mount 150mA DCR 1.5Ohm
Quick Inquiry
ACMS-Q3225E-101-T
Specifications
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Abracon LLC |
| Series | ACMS-Q3225E |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Signal Line |
| Number of Lines | 2 |
| Inductance @ Frequency | - |
| Current Rating (Max) | 150mA |
| DC Resistance (DCR) (Max) | 1.5Ohm |
| Voltage Rating - DC | 80V |
| Voltage Rating - AC | - |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | AEC-Q200 |
| Approval Agency | - |
| Features | - |
| Mounting Type | Surface Mount |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
| Height (Max) | 0.094" (2.40mm) |
| Package / Case | Horizontal, 4 PC Pad |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | ACMS-Q3225E-201-T | ACMS-Q3222F-101-T | ACMS-Q3225-101-T | ACMS-Q3225-110-T |
| Manufacturer | Abracon LLC | Abracon LLC | Abracon LLC | Abracon LLC |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CMC 200UH 70MA 2LN SMD AEC-Q200 | CMC 100UH 150MA 2LN SMD AEC-Q200 | CMC 100UH 150MA 2LN 5.1KOHM SMD | CMC 11UH 300MA 2LN 550OHM SMD |
| Series | ACMS-Q3225E | ACMS-Q3222F | ACMS-Q3225 | ACMS-Q3225 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
