ACNV3130-300E
lmages are for reference only.ACNV3130-300E
OPTOISO 7.5KV 1CH GT DVR 10DIP
Datasheet10-SMD, Gull Wing
89,023 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.5A Gate Driver Optical Coupling 7500Vrms 1 Channel 10-DIP Gull Wing
ACNV3130-300E
| Category | Isolators - Isolators Gate Drivers - |
| Manufacturer | Broadcom Limited |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Technology | Optical Coupling |
| Number of Channels | 1 |
| Voltage - Isolation | 7500Vrms |
| Common Mode Transient Immunity (Min) | 40kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 500ns, 500ns |
| Pulse Width Distortion (Max) | 300ns |
| Rise / Fall Time (Typ) | 100ns, 100ns |
| Current - Output High, Low | 2A, 2A |
| Current - Peak Output | 2.5A |
| Voltage - Forward (Vf) (Typ) | 1.6V |
| Voltage - Output Supply | 15V ~ 30V |
| Grade | - |
| Qualification | - |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Surface Mount |
| Package / Case | 10-SMD, Gull Wing |
| Supplier Device Package | 10-DIP Gull Wing |
| Approval Agency | CSA, IEC/EN/DIN, UR |
| Base Product Number | ACNV3130 |
| Current - DC Forward (If) (Max) | 25 mA |
| Product Attribute |  |
 |
 |
 |
| Part Number | ACNV3130-000E | ACNV3130-500E | ACNT-H313-000E | ACNT-H313-500E |
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | OPTOISO 7.5KV 1CH GATE DVR 10DIP | OPTOISO 7.5KV 1CH GT DVR 10DIP | OPTOISO 7.5KV 1CH GATE DVR 8SO | OPTOISO 7.5KV 1CH GATE DVR 8SO |
| Series | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) |
