AD5422BREZ-REEL
lmages are for reference only.AD5422BREZ-REEL
IC DAC 16BIT V OR A-OUT 24TSSOP
Datasheet24-TSSOP (0.173", 4.40mm Width) Exposed Pad
43,958 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
16 Bit Digital to Analog Converter 1 24-TSSOP-EP
AD5422BREZ-REEL
| Category | Integrated Circuits (ICs) - Data Acquisition - Digital to Analog Converters DAC |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Number of Bits | 16 |
| Number of D/A Converters | 1 |
| Settling Time | 25µs (V), 40µs (A) (Typ) |
| Output Type | Voltage or Current - Buffered |
| Differential Output | No |
| Data Interface | SPI, DSP |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 10.8V ~ 40V, -3V ~ 26.4V |
| Voltage - Supply, Digital | 2.7V ~ 5.5V |
| INL/DNL (LSB) | -, ±1.3 (Max) |
| Architecture | R-2R |
| Operating Temperature | -40°C ~ 105°C |
| Package / Case | 24-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 24-TSSOP-EP |
| Mounting Type | Surface Mount |
| Base Product Number | AD5422 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | AD5422BREZ | AD5422BREZ | AD5422BREZ-REEL | AD5420ACPZ-REEL |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC DAC 16BIT V OR A-OUT 24TSSOP | IC DAC 16BIT V OR A-OUT 24TSSOP | IC DAC 16BIT V OR A-OUT 24TSSOP | IC DAC 16BIT A-OUT 40LFCSP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
