Product CatalogPart Number
AHV24VN1500V5MAW
Manufacturer
Analog Technologies, Inc.Description
HV 24V to -1500V 7.5W DC-DC Conv
Datasheet
DatasheetPackage
-
In Stock
13,524 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AHV24VN1500V5MAW
AHV24VN1500V5MAW
lmages are for reference only.Payment Methods
Delivery Services
Enclosed DC DC Converter 1 Output 0 ~ -1500V 5mA 25V Input
Quick Inquiry
AHV24VN1500V5MAW
Specifications
| Category | Power Supplies - External/Internal (Off-Board) - DC DC Converters - |
| Manufacturer | Analog Technologies, Inc. |
| Series | - |
| Packaging | Tape & Box (TB) |
| RoHS Status | RoHS Compliant |
| Type | Enclosed |
| Voltage - Input (Min) | 23V |
| Voltage - Input (Max) | 25V |
| Number of Outputs | 1 |
| Voltage - Output 1 | 0 ~ -1500V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 5mA |
| Power (Watts) | 7.5W |
| Voltage - Isolation | - |
| Applications | ITE (Commercial) |
| Efficiency | 70% |
| Operating Temperature | -10°C ~ 55°C |
| Mounting Type | Chassis Mount |
| Size / Dimension | 4.11" L x 2.36" W x 1.10" H (104.4mm x 59.9mm x 27.9mm) |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | AHV24VN1500V10MAW | AHV24VN1500V1MAW | AHV24VN1500V2MAW | AHV24VN1500V3MAW |
| Manufacturer | Analog Technologies, Inc. | Analog Technologies, Inc. | Analog Technologies, Inc. | Analog Technologies, Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | HV 24V to -1500V 15W DC-DC Conve | HV 24V to -1500V 1.5W DC-DC Conv | HV 24V to -1500V 3W DC-DC Conver | HV 24V to -1500V 4.5W DC-DC Conv |
| Series | - | - | - | - |
| Packaging | Tape & Box (TB) | Tape & Box (TB) | Tape & Box (TB) | Tape & Box (TB) |
