Product CatalogPart Number
AP2141WG-7
Manufacturer
Diodes IncorporatedDescription
IC PWR SWITCH P-CHAN 1:1 SOT25
Datasheet
DatasheetPackage
SC-74A, SOT-753
In Stock
75,443 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AP2141WG-7
AP2141WG-7
lmages are for reference only.Payment Methods
Delivery Services
Power Switch/Driver 1:1 P-Channel 500mA SOT-25
Quick Inquiry
AP2141WG-7
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Switch Type | USB Switch |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | P-Channel |
| Interface | On/Off |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 500mA |
| Rds On (Typ) | 95mOhm |
| Input Type | Non-Inverting |
| Features | Load Discharge, Status Flag |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-25 |
| Package / Case | SC-74A, SOT-753 |
| Base Product Number | AP2141 |
| Grade | - |
| Qualification | - |
