AP3152FG-7
lmages are for reference only.AP3152FG-7
IC LED DRVR RGLTR DIM 30MA 12DFN
Datasheet12-UFDFN Exposed Pad
95,103 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 4 Output DC DC Regulator Switched Capacitor (Charge Pump) PWM Dimming 30mA U-DFN3030-12
AP3152FG-7
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Regulator |
| Topology | Switched Capacitor (Charge Pump) |
| Internal Switch(s) | Yes |
| Number of Outputs | 4 |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | - |
| Current - Output / Channel | 30mA |
| Frequency | 1.2MHz |
| Dimming | PWM |
| Applications | Backlight, Camera Flash |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 12-UFDFN Exposed Pad |
| Supplier Device Package | U-DFN3030-12 |
| Base Product Number | AP3152 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | AP3154AFG-7 | AP3156FVG-7 | PCA9922PW,118 | IS32LT3129A-ZLA3-TR |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | NXP USA Inc. | Lumissil Microsystems |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRVR RGLTR DIM 30MA 12DFN | IC LED DRIVER RGLTR 20MA 16QFN | IC LED DRVR LIN PWM 60MA 16TSSOP | IC LED DRV LIN PWM 20ETSSOP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
