AQW610EH
lmages are for reference only.AQW610EH
RELAY SPST-NO/NC 120MA 0-350V
Datasheet8-DIP (0.300", 7.62mm)
38,280 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Solid State SPST-NO + SPST-NC (1 Form A and B) 8-DIP (0.300", 7.62mm)
AQW610EH
| Category | Relays - Solid State Relays SSR - |
| Manufacturer | Panasonic Electric Works |
| Series | PhotoMOS™ AQW |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Through Hole |
| Circuit | SPST-NO + SPST-NC (1 Form A and B) |
| Output Type | AC, DC |
| Voltage - Input | 1.14VDC |
| Voltage - Load | 0 V ~ 350 V |
| Load Current | 120 mA |
| Termination Style | PC Pin |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-DIP |
| Approval Agency | UR, VDE |
| Grade | - |
| Qualification | - |
| Base Product Number | AQW610 |
| On-State Resistance (Max) | 25 Ohms |
| Product Attribute |  |
 |
 |
 |
| Part Number | AQW610EHA | AQW610EHAX | AQW610EHAZ | AQW610S |
| Manufacturer | Panasonic Electric Works | Panasonic Electric Works | Panasonic Electric Works | Panasonic Electric Works |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RELAY SPST-NO/NC 120MA 0-350V | RELAY SPST-NO/NC 120MA 0-350V | RELAY SPST-NO/NC 120MA 0-350V | RELAY SPST-NO/NC 100MA 0-350V |
| Series | PhotoMOS™ AQW | PhotoMOS™ AQW | PhotoMOS™ AQW | PhotoMOS™ AQW |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
