Product CatalogPart Number
ASNT5020
Manufacturer
ADSANTECDescription
17G Data/Clk Distributor 1-to-2
Datasheet
DatasheetPackage
24-VFQFN Exposed Pad
In Stock
78,945 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
ASNT5020
ASNT5020
lmages are for reference only.Payment Methods
Delivery Services
Splitter, Digital 1 x 1:3 Channel 24-QFN (4x4)
Quick Inquiry
ASNT5020
Specifications
| Category | Integrated Circuits (ICs) - Interface - Signal Buffers-Repeaters-Splitters |
| Manufacturer | ADSANTEC |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Splitter, Digital |
| Applications | - |
| Input | CML |
| Output | CML |
| Data Rate (Max) | - |
| Number of Channels | 1 x 1:3 |
| Delay Time | - |
| Signal Conditioning | - |
| Voltage - Supply | ±3.1V ~ 3.5V |
| Current - Supply | 170mA |
| Operating Temperature | -25°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 24-VFQFN Exposed Pad |
| Supplier Device Package | 24-QFN (4x4) |
| Base Product Number | - |
| Capacitance - Input | - |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | ASNT5020-PQD | ASNT5021 | ASNT5023 | ASNT5023-KMM |
| Manufacturer | ADSANTEC | ADSANTEC | ADSANTEC | ADSANTEC |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | 13G DATA/CLK DISTRIBUTOR 1-TO-2 | 17G Data/Clk Distributor 1-to-3 | 17G Data/Clk Distributor 1-to-4 | 17G Data/Clk Distributor 1-to-4 |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Retail Package |
