ATDR2-1/2
lmages are for reference only.ATDR2-1/2
CC TD FUSE 600V 2-1/2A ATDR
Datasheet5AG, 10mm x 38.1mm
55,747 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.5A 600 VAC 300 VDC Fuse Cartridge Requires Holder
ATDR2-1/2
| Category | Circuit Protection - Electrical-Specialty Fuses - |
| Manufacturer | Mersen USA Newburyport-MA L.L.C. |
| Series | ATDR |
| Packaging | Box |
| RoHS Status | RoHS non-compliant |
| Mounting Type | Requires Holder |
| Fuse Type | Cartridge |
| Current Rating (Amps) | 2.5A |
| Voltage Rating - AC | 600 VAC |
| Response Time | Slow Blow |
| Applications | Electrical, Industrial |
| Features | - |
| Class | CC |
| Approval Agency | CE, CSA, UL |
| Operating Temperature | - |
| Breaking Capacity @ Rated Voltage | 200kA AC, 100kA DC |
| Package / Case | 5AG, 10mm x 38.1mm |
| Size / Dimension | 0.409" Dia x 1.500" L (10.40mm x 38.10mm) |
| Base Product Number | - |
| Voltage Rating - DC | 300 VDC |
| Grade | - |
| Qualification | - |
| Melting I²t | - |
| DC Cold Resistance | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ATDR1 | ATDR1-1/2 | ATDR1-1/4 | ATDR1-6/10 |
| Manufacturer | Mersen USA Newburyport-MA L.L.C. | Mersen USA Newburyport-MA L.L.C. | Mersen USA Newburyport-MA L.L.C. | Mersen USA Newburyport-MA L.L.C. |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | CC TD FUSE 600V 1A ATDR | CC TD FUSE 600V 1-1/2A ATDR | CC TD FUSE 600V 1-1/4A ATDR | CC TD FUSE 600V 1-6/10A ATDR |
| Series | ATDR | ATDR | ATDR | ATDR |
| Packaging | Box | Box | Box | Box |
