ATF1504AS-15JC84
Manufacturer
AtmelDescription
IC CPLD 64MC 15NS 84PLCC
Datasheet
DatasheetPackage
84-LCC (J-Lead)
In Stock
19,529 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
ATF1504AS-15JC84
ATF1504AS-15JC84
lmages are for reference only.Payment Methods
Delivery Services
Quick Inquiry
ATF1504AS-15JC84
Specifications
| Category | Integrated Circuits (ICs) - Embedded - CPLDs Complex Programmable Logic Devices |
| Manufacturer | Atmel |
| Series | ATF15xx |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Programmable Type | In System Programmable (min 10K program/erase cycles) |
| Delay Time tpd(1) Max | 15 ns |
| Voltage Supply - Internal | 4.75V ~ 5.25V |
| Number of Logic Elements/Blocks | - |
| Number of Macrocells | 64 |
| Number of Gates | - |
| Number of I/O | 64 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 84-LCC (J-Lead) |
| Supplier Device Package | 84-PLCC (29.31x29.31) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
