AVRF060X8R2LT272
lmages are for reference only.AVRF060X8R2LT272
ESD NOTCH FILTER 7VDC/2.7GHZ
Datasheet0201 (0603 Metric)
51,091 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
EMI Filter Order Channel C = 8.2pF 0201 (0603 Metric)
AVRF060X8R2LT272
| Category | Filters - EMI-RFI Filters LC-RC Networks - |
| Manufacturer | TDK Corporation |
| Series | AVRF |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | - |
| Filter Order | - |
| Technology | - |
| Center / Cutoff Frequency | - |
| Attenuation Value | 20dB @ 2.7GHz |
| Resistance - Channel (Ohms) | - |
| Current | - |
| Values | C = 8.2pF |
| ESD Protection | Yes |
| Operating Temperature | -55°C ~ 85°C |
| Applications | Audio |
| Voltage - Rated | 7V |
| Mounting Type | Surface Mount |
| Package / Case | 0201 (0603 Metric) |
| Size / Dimension | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
| Height | 0.012" (0.30mm) |
| Number of Channels | - |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | AVRF060X8R2LT272 | AVRF060V600MT102 | AVRF060V600MT102 | AVRF060W650MT102 |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | ESD NOTCH FILTER 7VDC/2.7GHZ | ESD NOTCH FILTER 3.5VDC/1GHZ | ESD NOTCH FILTER 3.5VDC/1GHZ | ESD NOTCH FILTER 5.5VDC/1GHZ |
| Series | AVRF | AVRF | AVRF | AVRF |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
