AX8052F131-2-TX30
Manufacturer
onsemiDescription
IC RF TXRX+MCU 802.15.4 40QFN
Datasheet
DatasheetPackage
40-VFQFN Exposed Pad
In Stock
88,393 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AX8052F131-2-TX30
AX8052F131-2-TX30
lmages are for reference only.Payment Methods
Delivery Services
IC RF TxRx + MCU 802.15.4, General ISM < 1GHz Zigbee® 400MHz ~ 470MHz, 800MHz ~ 940MHz 40-VFQFN Exposed Pad
Quick Inquiry
AX8052F131-2-TX30
Specifications
| Category | RF and Wireless - RF Transceiver ICs - |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Type | TxRx + MCU |
| RF Family/Standard | 802.15.4, General ISM < 1GHz |
| Protocol | Zigbee® |
| Modulation | 4FSK, ASK, FSK, GFSK, MSK, O-QPSK, PSK |
| Frequency | 400MHz ~ 470MHz, 800MHz ~ 940MHz |
| Data Rate (Max) | 2Mbps |
| Power - Output | 16dBm |
| Sensitivity | -116dBm |
| Memory Size | 64kB Flash, 8.25kB SRAM |
| Serial Interfaces | SPI, UART |
| GPIO | 21 |
| Voltage - Supply | 2.2V ~ 3.6V |
| Current - Receiving | - |
| Current - Transmitting | 13mA ~ 45mA |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 40-VFQFN Exposed Pad |
| Supplier Device Package | 40-QFN (7x5) |
| Base Product Number | AX8052 |
| Grade | - |
| Qualification | - |
