AZ1117H-3.3TRE1
lmages are for reference only.AZ1117H-3.3TRE1
IC REG LINEAR 3.3V 1A SOT223
DatasheetTO-261-4, TO-261AA
62,734 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 1A SOT-223-3
AZ1117H-3.3TRE1
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Diodes Incorporated |
| Series | AZ1117 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 15V |
| Voltage - Output (Min/Fixed) | 3.3V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 1.25V @ 1A |
| Current - Output | 1A |
| Current - Quiescent (Iq) | 10 mA |
| PSRR | 75dB (120Hz) |
| Control Features | - |
| Protection Features | Thermal Shutdown |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-261-4, TO-261AA |
| Supplier Device Package | SOT-223-3 |
| Base Product Number | AZ1117 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | AZ1117H-3.3TRG1 | AZ1117BH-1.2TRE1 | AZ1117BH-1.8TRE1 | AZ1117BH-2.5TRE1 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LINEAR 3.3V 1A SOT223 | IC REG LINEAR 1.2V 850MA SOT223 | IC REG LINEAR 1.8V 850MA SOT223 | IC REG LINEAR 2.5V 850MA SOT223 |
| Series | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
