AZ23C75-HE3_A-08
Manufacturer
VishayDescription
ZENER DIODE SOT23
Datasheet
DatasheetPackage
TO-236-3, SC-59, SOT-23-3
In Stock
79,768 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AZ23C75-HE3_A-08
AZ23C75-HE3_A-08
lmages are for reference only.Payment Methods
Delivery Services
Zener Diode Array 1 Pair Common Anode 75 V 300 mW ±5% SOT-23-3
Quick Inquiry
AZ23C75-HE3_A-08
Specifications
| Category | Discrete Semiconductor Products - Diodes - Zener |
| Manufacturer | Vishay |
| Series | AZ23 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Configuration | 1 Pair Common Anode |
| Voltage - Zener (Nom) (Vz) | 75 V |
| Tolerance | ±5% |
| Power - Max | 300 mW |
| Impedance (Max) (Zzt) | 250 Ohms |
| Current - Reverse Leakage @ Vr | 50 nA @ 56 V |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 |
| Base Product Number | - |
| Voltage - Forward (Vf) (Max) @ If | - |
| Grade | Automotive |
| Qualification | AEC-Q101 |
