RELAY GEN PURPOSE DPDT 10A 120V
Datasheet-
17,698 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay DPDT (2 Form C) 120VDC Coil Chassis Mount
B07D034BE2-0135
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | 07, CII |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Mounting Type | Chassis Mount |
| Coil Voltage | 120VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 10 A |
| Switching Voltage | 28VDC - Nom |
| Load - Max Switching | - |
| Coil Current | 15.8 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Hermetically |
| Coil Insulation | - |
| Must Operate Voltage | 65 VDC |
| Must Release Voltage | 7.7 VDC |
| Operate Time | 15 ms |
| Release Time | 15 ms |
| Operating Temperature | -65°C ~ 125°C |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Approval Agency | - |
| Relay Type | General Purpose |
| Grade | Military |
| Qualification | MIL-R-5757/23 |
| Coil Resistance | 7.6 kOhms |
| Base Product Number | B07D03 |
| Product Attribute |  |
|
 |
 |
| Part Number | B07D012BC1-0459 | B07D034BA2-0125 | B07D034BB2-0120 | B07D034BC2-0053 |
| Manufacturer | TE Connectivity | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | General Purpose Relays B07D012BC | B07D034BA2-0125 = M5757/23-015 | RELAY GEN PURPOSE DPDT 10A 12V | RELAY GEN PURPOSE DPDT 10A 26.5V |
| Series | TE Connectivity | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| Packaging | Tray | Bulk | Bulk | Bulk |
