B32656S1105K566
lmages are for reference only.B32656S1105K566
CAP FILM 1UF 10% 100VDC SCREW
DatasheetRectangular Box
85,837 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1 µF Film Capacitor 100V Rectangular Box
B32656S1105K566
| Category | Capacitors - Film Capacitors - |
| Manufacturer | EPCOS - TDK Electronics |
| Series | B3265* - MKP General Purpose |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 1 µF |
| Tolerance | ±10% |
| Voltage Rating - AC | - |
| Voltage Rating - DC | 100V |
| Dielectric Material | - |
| Operating Temperature | - |
| Mounting Type | Chassis Mount |
| Package / Case | Rectangular Box |
| Size / Dimension | - |
| Height - Seated (Max) | - |
| Termination | Screw Terminals |
| Lead Spacing | 0.945" (24.00mm) |
| Applications | Snubber |
| Ratings | - |
| Features | Low ESL |
| ESR (Equivalent Series Resistance) | - |
| Base Product Number | - |
| Product Attribute | |
|
 |
 |
| Part Number | B32656S1104K564 | B32656S1105K577 | B32651A7222J000 | B32651A7222K000 |
| Manufacturer | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP FILM 0.1UF 10% 100VDC SCREW | CAP FILM 1UF 10% 100VDC SCREW | CAP FILM 2200PF 5% 1.25KVDC RAD | CAP FILM 2200PF 10% 1.25KVDC RAD |
| Series | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| Packaging | Bulk | Bulk | Bulk | Bulk |
