BAS3005A02VH6327XTSA1
lmages are for reference only.BAS3005A02VH6327XTSA1
DIODE SCHOTTKY 30V 500MA SC79-2
DatasheetSC-79, SOD-523
45,712 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Diode 30 V 500mA Surface Mount PG-SC79-2
BAS3005A02VH6327XTSA1
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 30 V |
| Current - Average Rectified (Io) | 500mA |
| Voltage - Forward (Vf) (Max) @ If | 500 mV @ 500 mA |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | - |
| Current - Reverse Leakage @ Vr | 300 µA @ 30 V |
| Capacitance @ Vr, F | 15pF @ 5V, 1MHz |
| Mounting Type | Surface Mount |
| Package / Case | SC-79, SOD-523 |
| Supplier Device Package | PG-SC79-2 |
| Operating Temperature - Junction | -55°C ~ 125°C |
| Base Product Number | BAS3005 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | BAS3005B02VH6327XTSA1 | BAS3005S-02LRHE6327 | BAS3005S02LRHE6327XTSA1 | VS-HFA25PB60-N3 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | Not applicable | ROHS3 Compliant | ROHS3 Compliant |
| Description | DIODE SCHOTTKY 30V 500MA SC79-2 | DIODE SCHOTT 30V 500MA TSLP-2-17 | DIODE SCHOTT 30V 500MA TSLP-2-17 | DIODE GP 600V 25A TO247AC |
| Series | - | BAS | - | HEXFRED® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
