BAT42WS-TP
Manufacturer
Micro Commercial CoDescription
DIODE SCHOTTKY 30V 100MA SOD323
Datasheet
DatasheetPackage
SC-76, SOD-323
In Stock
23,842 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
BAT42WS-TP
BAT42WS-TP
lmages are for reference only.Payment Methods
Delivery Services
Diode 30 V 100mA Surface Mount SOD-323
Quick Inquiry
BAT42WS-TP
Specifications
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 30 V |
| Current - Average Rectified (Io) | 100mA |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 200 mA |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 5 ns |
| Current - Reverse Leakage @ Vr | 500 nA @ 25 V |
| Capacitance @ Vr, F | 10pF @ 1V, 1MHz |
| Mounting Type | Surface Mount |
| Package / Case | SC-76, SOD-323 |
| Supplier Device Package | SOD-323 |
| Operating Temperature - Junction | -55°C ~ 125°C |
| Base Product Number | BAT42 |
| Grade | - |
| Qualification | - |
