BAT54LT3G
Manufacturer
onsemiDescription
DIODE SCHOTTKY 30V 200MA SOT23-3
Datasheet
DatasheetPackage
TO-236-3, SC-59, SOT-23-3
In Stock
20,545 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
BAT54LT3G
BAT54LT3G
lmages are for reference only.Payment Methods
Delivery Services
Diode 30 V 200mA Surface Mount SOT-23-3 (TO-236)
Quick Inquiry
BAT54LT3G
Specifications
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 30 V |
| Current - Average Rectified (Io) | 200mA |
| Voltage - Forward (Vf) (Max) @ If | 800 mV @ 100 mA |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 5 ns |
| Current - Reverse Leakage @ Vr | 2 µA @ 25 V |
| Capacitance @ Vr, F | 10pF @ 1V, 1MHz |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 (TO-236) |
| Operating Temperature - Junction | -55°C ~ 125°C |
| Base Product Number | BAT54 |
| Grade | - |
| Qualification | - |
