BFM-1M05C
lmages are for reference only.BFM-1M05C
2000V/3.0A REED RELAY, 1 FORM A
Datasheet-
85,725 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
BFM-1M05C
| Category | Relays - Reed Relays - |
| Manufacturer | Bright Toward Industrial Co., Ltd. |
| Series | BFM |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Through Hole |
| Coil Voltage | 5VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 2 A |
| Switching Voltage | 1500VDC - Max |
| Coil Type | Non Latching |
| Features | Coaxial Shield |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Hermetically |
| Must Operate Voltage | 3.8 VDC |
| Must Release Voltage | 0.4 VDC |
| Operating Temperature | -25°C ~ 85°C |
| Contact Material | - |
| Coil Resistance | 75 Ohms |
| Coil Current | 67 mA |
| Operate Time | 2 ms |
| Release Time | 1.5 ms |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | BFM-1M12E | BFM-1A-05 | BFM-1A-05C | BFM-1A-05CW |
| Manufacturer | Bright Toward Industrial Co., Ltd. | Comus International | Comus International | Comus International |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 2000V/3.0A REED RELAY, 1 FORM A | RELAY REED SPST .5A 5V | RELAY REED SPST .5A 5V | RELAY REED SPST .5A 5V |
| Series | BFM | BFM | BFM | BFM-CW |
| Packaging | Tube | Tube | Tube | Tube |
