BRT22F-X009
lmages are for reference only.BRT22F-X009
PHOTOCOUPLER TRIAC
Datasheet6-SMD, Gull Wing
40,727 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Triac Output 5300Vrms 1 Channel 6-SMD
BRT22F-X009
| Category | Isolators - Optoisolators - Triac-SCR Output Optoisolators |
| Manufacturer | Vishay Semiconductor Opto Division |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Output Type | Triac |
| Zero Crossing Circuit | Yes |
| Number of Channels | 1 |
| Voltage - Isolation | 5300Vrms |
| Voltage - Off State | 600 V |
| Static dV/dt (Min) | 10kV/µs |
| Current - LED Trigger (Ift) (Max) | 1.2mA |
| Current - Hold (Ih) | 500µA |
| Turn On Time | 35µs |
| Voltage - Forward (Vf) (Typ) | 1.16V |
| Current - DC Forward (If) (Max) | 60 mA |
| Operating Temperature | -40°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, Gull Wing |
| Supplier Device Package | 6-SMD |
| Approval Agency | cUL, UR, VDE |
| Base Product Number | BRT22 |
| Current - On State (It (RMS)) (Max) | 300 mA |
| Product Attribute | |
|
 |
 |
| Part Number | BRT22F-X007 | BRT22F-X017T | BRT22-F | BRT22-H |
| Manufacturer | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | PHOTOCOUPLER TRIAC | PHOTOCOUPLER TRIAC | PHOTOCOUPLER TRIAC 600V 6DIP | PHOTOCOUPLER TRIAC 600V 6DIP |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Tube | Tube |
