BSM20GD60DLC
Manufacturer
Infineon TechnologiesDescription
IGBT MODULE
Datasheet
DatasheetPackage
Module
In Stock
26,539 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
BSM20GD60DLC
BSM20GD60DLC
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Full Bridge 600 V 32 A 125 W Chassis Mount
Quick Inquiry
BSM20GD60DLC
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Configuration | Full Bridge |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 32 A |
| Power - Max | 125 W |
| Vce(on) (Max) @ Vge, Ic | 2.45V @ 15V, 20A |
| Current - Collector Cutoff (Max) | 500 µA |
| Input Capacitance (Cies) @ Vce | 1.1 nF @ 25 V |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | - |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute | |
|
 |
|
| Part Number | BSM20GD60DLCE3224 | BSM20GP60BOSA1 | BSM100GB60DLCHOSA1 | BSM35GP120BPSA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IGBT MODULE | IGBT MODULE 600V 35A 130W | IGBT MOD 600V 130A 445W | LOW POWER ECONO AG-ECONO2C-211 |
| Series | - | - | - | - |
| Packaging | Bulk | Tray | Bulk | Tray |
