C5750X7R1E685K160KM
lmages are for reference only.C5750X7R1E685K160KM
CAP CER 6.8UF 25V X7R 2220
Datasheet2220 (5750 Metric)
12,545 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
6.8 µF ±10% 25V Ceramic Capacitor X7R 2220 (5750 Metric)
C5750X7R1E685K160KM
| Category | Capacitors - Ceramic Capacitors - |
| Manufacturer | TDK Corporation |
| Series | C |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 6.8 µF |
| Tolerance | ±10% |
| Voltage - Rated | 25V |
| Temperature Coefficient | X7R |
| Operating Temperature | -55°C ~ 125°C |
| Features | - |
| Ratings | - |
| Applications | General Purpose |
| Failure Rate | - |
| Mounting Type | Surface Mount, MLCC |
| Package / Case | 2220 (5750 Metric) |
| Size / Dimension | 0.224" L x 0.197" W (5.70mm x 5.00mm) |
| Height - Seated (Max) | - |
| Thickness (Max) | 0.071" (1.80mm) |
| Lead Spacing | - |
| Lead Style | - |
| Base Product Number | - |
| Product Attribute | |
|
|
 |
| Part Number | C5750X7R1C226M280KA | C5750X7R1C226M280KM | C5750X7R1C336M200KB | C5750X7R1C476M230KB |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP CER 22UF 16V X7R 2220 | CAP CER 22UF 16V X7R 2220 | CAP CER 33UF 16V X7R 2220 | CAP CER 47UF 16V X7R 2220 |
| Series | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
