Product CatalogPart Number
CAT3604HS4-TE13
Manufacturer
onsemiDescription
IC LED DRV RGLTR PWM 30MA 16TQFN
Datasheet
DatasheetPackage
16-WQFN Exposed Pad
In Stock
79,526 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CAT3604HS4-TE13
CAT3604HS4-TE13
lmages are for reference only.Payment Methods
Delivery Services
LED Driver IC 4 Output DC DC Regulator Switched Capacitor (Charge Pump) PWM Dimming 30mA 16-TQFN (4x4)
Quick Inquiry
CAT3604HS4-TE13
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Type | DC DC Regulator |
| Topology | Switched Capacitor (Charge Pump) |
| Internal Switch(s) | Yes |
| Number of Outputs | 4 |
| Voltage - Supply (Min) | 3V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | - |
| Current - Output / Channel | 30mA |
| Frequency | 1MHz |
| Dimming | PWM |
| Applications | Backlight, Camera Flash |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-WQFN Exposed Pad |
| Supplier Device Package | 16-TQFN (4x4) |
| Base Product Number | CAT3604 |
| Grade | - |
| Qualification | - |
