CC2510F32RHHT
lmages are for reference only.CC2510F32RHHT
IC RF TXRX+MCU ISM>1GHZ 36VQFN
Datasheet36-VFQFN Exposed Pad
27,953 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IC RF TxRx + MCU General ISM > 1GHz 2.4GHz 36-VFQFN Exposed Pad
CC2510F32RHHT
| Category | RF and Wireless - RF Transceiver ICs - |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | TxRx + MCU |
| RF Family/Standard | General ISM > 1GHz |
| Protocol | - |
| Modulation | 2FSK, GFSK, MSK |
| Frequency | 2.4GHz |
| Data Rate (Max) | 500kBaud |
| Power - Output | 1dBm |
| Sensitivity | -103dBm |
| Memory Size | 32kB Flash, 4kB SRAM |
| Serial Interfaces | I2S, SPI, USART |
| GPIO | 21 |
| Voltage - Supply | 2V ~ 3.6V |
| Current - Receiving | 14.7mA ~ 22.9mA |
| Current - Transmitting | 15.5mA ~ 26mA |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 36-VFQFN Exposed Pad |
| Supplier Device Package | 36-VQFN (6x6) |
| Base Product Number | CC2510F32 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | CC2510F32RHHR | CC2510F32RSP | CC2510F32RSPR | CC2510F32RSPRG3 |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC RF TXRX+MCU ISM>1GHZ 36VQFN | IC RF TXRX+MCU ISM>1GHZ 36VQFN | IC RF TXRX+MCU ISM>1GHZ 36VQFN | IC RF TXRX+MCU ISM>1GHZ 36VQFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tray | Tape & Reel (TR) | Tape & Reel (TR) |
