CDEP134-2R7MC-H
lmages are for reference only.CDEP134-2R7MC-H
FIXED IND 2.7UH 8A 10.8 MOHM SMD
DatasheetNonstandard
53,485 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.7 µH Shielded Drum Core, Wirewound Inductor 8 A 10.8mOhm Max Nonstandard
CDEP134-2R7MC-H
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Sumida America Components Inc. |
| Series | CDEP134 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 2.7 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 8 A |
| Current - Saturation (Isat) | 14.7A |
| Shielding | Shielded |
| DC Resistance (DCR) | 10.8mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.531" L x 0.531" W (13.50mm x 13.50mm) |
| Height - Seated (Max) | 0.197" (5.00mm) |
| Base Product Number | - |
| Product Attribute |  |
|
 |
|
| Part Number | CDEP134-2R5MC | CDEP134-2R7MC-H | CDEP104NP-0R2NC-50 | CDEP104NP-0R3NC-88 |
| Manufacturer | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 2.5UH 10.5A 6.6MOHM SM | FIXED IND 2.7UH 8A 10.8 MOHM SMD | FIXED IND 220NH 18A 2.2 MOHM SMD | FIXED IND 360NH 18A 2.2 MOHM SMD |
| Series | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
