Product CatalogPart Number
CH88102C100-B
Manufacturer
Cvilux USADescription
2.54MM(.100) DUAL ROW BOARD MOUN
Datasheet
DatasheetPackage
-
In Stock
32,796 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CH88102C100-B
CH88102C100-B
lmages are for reference only.Payment Methods
Delivery Services
Connector Header Through Hole 10 position 0.100" (2.54mm)
Quick Inquiry
CH88102C100-B
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Male Pins |
| Manufacturer | Cvilux USA |
| Series | CH88 |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Header |
| Contact Type | Male Pin |
| Pitch - Mating | 0.100" (2.54mm) |
| Number of Positions | 10 |
| Number of Rows | 2 |
| Row Spacing - Mating | 0.100" (2.54mm) |
| Number of Positions Loaded | All |
| Style | Board to Board or Cable |
| Shrouding | Shrouded - 4 Wall |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Latch Lock/Eject Hooks, Short |
| Contact Length - Mating | - |
| Contact Length - Post | 0.134" (3.40mm) |
| Overall Contact Length | - |
| Insulation Height | 0.658" (16.71mm) |
| Contact Shape | Square |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | Flash |
| Contact Finish - Post | Gold |
| Contact Material | Brass |
| Insulation Material | Polyester, Glass Filled |
| Features | Keying Slot |
| Operating Temperature | -40°C ~ 105°C |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Insulation Color | Black |
| Current Rating (Amps) | 3A |
| Voltage Rating | 250VAC |
| Mated Stacking Heights | - |
| Contact Finish Thickness - Post | Flash |
| Applications | - |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | CH88102A100-B | CH88102B100-B | CH87062M1P0-R0 | CH87062V200 |
| Manufacturer | Cvilux USA | Cvilux USA | Cvilux USA | Cvilux USA |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 2.54MM(.100) DUAL ROW BOARD MOUN | 2.54(.100) DUAL ROW BOARD MOUNT | CH87 SERIES 2.54MM(.100) DUAL RO | 2.54MM(.100) DUAL ROW BOARD STRA |
| Series | CH88 | CH88 | CH87 | CH87 |
| Packaging | Tray | Tray | Tape & Reel (TR)-->Cut Tape (CT) | Tray |
